| Item | Unit | Description | |
| Spindle | Spindle unit | BT40-120mm | |
| Speed | r/min | 50~8000 | |
| Spindle end face to worktable | mm | 120-520 | |
| Spindle center to column | mm | 460 | |
| Worktable | Worktable size | mm | 760×400 |
| T-slot number, width and spacing | mm | 5×18×80 | |
| Max. load | kg | 300 | |
| Guide rail | Guide rail type | Roller linear guide for X, Y, Z axis | |
| Guide rail width for X, Y, Z axis | mm | 35/35/35 | |
| Roller guide screw | X axis | mm | φ40×12 |
| Y axis | mm | φ40×12 | |
| Z axis | mm | φ40×12 | |
| Travel | X axis | mm | 600 |
| Y axis | mm | 400 | |
| Z axis | mm | 400 | |
| Fast moving speed | X axis | m/min | 24 |
| Y axis | m/min | 24 | |
| Z axis | m/min | 22 | |
| Cutting feed speed | m/min | 1-8000 | |
| Control system | Fanuc | ||
| Servo motor | Spindle motor | KW | 5.5 |
| X, Y axis servo motor | βis8/3000 | ||
| Z axis servo motor | Βis12/3000 | ||
| Positioning accuracy for X, Y, Z axis | mm | 300/±0.005 | |
| Repeatability accuracy for X, Y, Z axis | mm | 300/±0.003 | |
| Air pressure | MPa | 0.6-0.8 | |
| Machine weight | kg | 4600 | |
| Machine size(L×W×H) | mm | 2650×2100×2500mm | |
| No. | Name | No. | Name |
| 1 | Spindle pneumatic loose broach | 8 | Z-direction stainless steel cover |
| 2 | Handheld air gun | 9 | Anchor bolts and pads |
| 3 | Automatic lubrication system | 10 | Cooling horizontal water pump 270W |
| 4 | LED warning light | 11 | Rigid tapping |
| 5 | Electrical box dustproof device | 12 | RS-232 interface and USB function |
| 6 | 24V work light | 13 | Power distribution box safety lock |
| 7 | XY guide rail stainless steel guard |
| Item | Quantity | Manufacturer |
| Control system | 1 set | Fanuc |
| Spindle servo motor | 1 set | Fanuc |
| Spindle driver | 1 set | Fanuc |
| X, Y, Z axis servo motor | 1 set for each | Fanuc |
| X, Y, Z axis driver | 1 set for each | Fanuc |
| X, Y, Z axis screw bearing | 1 set for each | Japan NSK |
| X, Y, Z axis ball screw φ40×12 | 1 set for each | Taiwan |
| X, Y, Z axis roller rail 35mm | 1 set for each | Taiwan |
| Locking nut | 1 set | Taiwan |
| Spindle unit BT40-120mm | 1 set | Taiwan |
| Main pneumatic components | 1 set | Taiwan |
| Main electrical components | 1 set | Germany |
| Automatic lubrication system | 1 set | HERG |
| Synchronous pulley and synchronous belt | 1 set | Taiwan |
| Cutting fluid pump | 1 set | Changzhou |
| Electrical cabinet switch | 1 set | Tongfei |
| Cylinder 4.5T | 1 pc | Guoding |
| Electronic handwheel | 1 pc | Shanghai |
| Operation panel | 1 pc | Shanghai |
